Feature
Technical details
- It can equip with various engine brand
- AVR for control voltage
- For DC welding and AC generator output and air compressor
- MDS rectifier system
- Two stages air compressor for high pnumatical tools
- Large tank for air compressor higher ef ciency
- It can welding 4.0mm electrode for long time
- Can output AC 5.0kw steadily
- Can use for industrial pnumatical tools
- Duty Cycle0.5
- OCV（V)DC75
- Current range(A)DC 50-200
- Welding voltage(V)DC 22-28V
- Welding rod1.6-5.0mm
- Rated current/voltage(A/V)170A / 26.8V
- Auxiliary rated power output4.2kW AC 240V or 120V
- Engine ModelCH440
- Max.power/Speed(RPM)--8.5kW/3600rpm
- Displacement(cc)Gas
- Start methodRecoil/E-start
- Capacity(L)200
- Stage2
- Flow500L/min
- Pressure range0.9-1.2Mpa
- Fuel tank capacity(L)6.5
- Protection classIP21
- Dimension(mm)1300*750*1250（with bottom bracket: 1350）
- Net weight(kg)380
