Feature
Technical details
- •More powerful;5%-8% power increasing.
- •Advanced square-shaped alternator;high efficiency;increase power output.
- •Noise insulation system; latest muffler structure; better noise insulation effect.
- •Water proof design;challenges toughest environment.
- •Pressurized air intake system;increase power out; minimizes emission.
- Frequency50HZ/60HZ
- Rated power3.2kW/3.5kW
- Max. power3.8kW/4.1kW
- AC Voltage120V/240V
- PhaseSingle
- Fuel capacity15L
- Run time@50%load9.0h
- Engine modelSC230
- Displacement223cc
- Max. output7.5HP/3600rpm
- Start systemRecoil/E-start
- Dimensions620*485*530mm
- Net weight48kgs
- Loading Q’ty(20GP/40HQ)168/430
