Feature
Technical details
- More powerful;5%-8% power increasing
- Professional chemical pump
- High flow capacity
- High strength frame
- Easy starting and operation;Smaller vibration
- PH4 – PH11
- EngineAP168FB
- Starting SystemRecoil
- Displacement196cc
- Bore*Stroke68*54mm
- Suction Port Diameter50mm
- Discharge Port Diameter50mm
- Total Head Lift30m
- Discharge Capacity30m³/h
- Suction Head7m
- Rated Speed3600rpm
- Fuel Tank Capacity3.6L
- Dimensions540*410*420mm
- Net Weight25.0kgs
- Loading Qty(20GP/40HQ)300/744
