Feature
Technical details
- •Advanced OHV; air-cooled; 4-stroke.
- •Less noisy.
- •Easy starting and operation.
- •Smaller vibration.
- •Lower oil temperature.
- •Low oil consumption.
- Engine typeSingle cylinder;4 Stroke; Forced Cooling OHV
- Bore X Stroke (mm)70*51
- Displacement196cc
- Compression8.5:1
- Starting MethodRecoil start
- Ignition methodTransistorized ignition
- Lubrication methodSplash
- Rated Output(Kw-r/min)3.5-3600
- Max torque(N.m-r/min)11.0-2500
- Min. Fuel consumption(g/Kw.h)<=374
- Dimensions L*W*H(mm)380*325*270mm
- Net Weight(kgs)14.0
- Loading Q’ty(20GP/40HQ)864/1989
