Feature
Technical details
- More powerful; 5%-8% power increasing
- Surrounded cooling shield; lower
oil temperature brings long life
- Less noisy; rocker arm with fixed pin shaft type
has good performance of high precision
- Low oil sensor
- Electronic Fuel Injection (EFI) system (optional)
- Easy starting and operation
- Smaller vibration
- Engine typesingle cylinder;4 Stroke;Forced Cooling OHV
- Bore x Stroke(mm)68x54
- Displacement196cc
- Compression8.5:1
- Starting methodRecoil/E-start
- Ignition methodTransistorized ignition
- Lubrication methodSplash
- Rated output(Kw-r/min)4.2-3600
- Max torque(N.m-r/min)11.0-2500
- Min.fuel consumption(g/Kw.h)≤374
- Dimensiones L*W*H(mm)380*325*335
- Net weight(kgs)16.3
- Loading Qty(20GP/40HQ768/1782
