Feature
Technical details
- More powerful; 5%-8% power increasing
- Surrounded cooling shield; lower
oil temperature brings long life
- Less noisy; rocker arm with fixed pin shaft type
has good performance of high precision
- Low oil sensor
- Electronic Fuel Injection (EFI) system (optional)
- Easy starting and operation
- Smaller vibration
- Engine typesingle cylinder;4 Stroke;Forced Cooling OHV
- Bore x Stroke(mm)70x58
- Displacement223cc
- Compression9.2:1
- Starting methodRecoil/E-start
- Ignition methodTransistorized ignition
- Lubrication methodSplash
- Rated output(Kw-r/min)5.0-3600
- Max torque(N.m-r/min)12.5-2500
- Min.fuel consumption(g/Kw.h)≤374
- Dimensiones L*W*H(mm)420*365*395
- Net weight(kgs)16.3
- Loading Qty(20GP/40HQ435/1074
