Feature
Technical details
- More powerful; 5%-8% power increasing
- Surrounded cooling shield; lower oil temperature brings long life
- Less noisy; rocker arm with fixed pin shaft type
has good performance of high precision
- Low oil sensor
- Electronic Fuel Injection (EFI) system (optional)
- Easy starting and operation
- Smaller vibration
- Engine typesingle cylinder;4 Stroke;Forced Cooling OHV
- Bore x Stroke(mm)90x66
- Displacement420cc
- Compression8.5:1
- Starting methodRecoil/E-start
- Ignition methodTransistorized ignition
- Lubrication methodSplash
- Rated output(Kw-r/min)9.5-3600
- Max torque(N.m-r/min)28.0-2500
- Min.fuel consumption(g/Kw.h)≤370
- Dimensiones L*W*H(mm)510*420*490
- Net weight(kgs)31.0
- Loading Qty(20GP/40HQ236/625
