Feature
Technical details
- Intelligent digital core precision regulation
- Functional diversification(thrust+thermal arcignition+anti-sticking+memory)
- Output current/voltage double display
- Supporting generator matching mode
- Equal current output with diffrent input voltages
- Automatic start and stop of fan
- Overall protection of chassis
- Input PowerAC 220/380V
- Voltage Range120-560V
- Output Current Range(A)180A
- Duty Cycle(%)(@40℃40
- Power Factor(COS)0.7
- NO-load Voltage(V)65-75
- Insulation Class F
- Electrod(mm)2.5-4.0mm
- Efficency(%)60
- Protection ClassIP21S
- Weight(kg)8.5
- Dimension(mm)375*150*280
