Feature
Technical details
- High speed;high power;compared with the same displacement product comprehensive power increase by 5%
- Special high - revolution spark plug to ensure stronger discharge and improve ignition capability.
- Low fuel consumption;low emission
- Easy starting and operation;Smaller vibration.
- Engine typesingle cylinder;4 Stroke;Forced Cooling OHV
- Bore and Stroke(mm)70x58
- Displacement223cc
- Compression8.5:1
- Starting methodRecoil Start
- Ignition methodTransistorized Ignition
- Lubrication methodSplash
- Net output(Kw-r/min) 4.6-4400
- Max torque(N.m-r/min)11.5-4000
- Min.fuel consumption(g/Kw.h)≤374
- Dimensiones L*W*H(mm)370*320*360
- Net weight(kgs)15
- Loading Qty (20GP/40HQ)445/1098
